- P/N: CMA-0254
- Rated Voltage&Current: DC 12V 1A
- Life test: 50,000 cycles
- Environment: anti-corrosion, 48 hours salt-spray test
- Pass Rohs, reach, HF, environmental protectionl
[CMA-0254] 4 Pin square male and female magnetic cable connector
Description
4 Pin square male and female magnetic cable connector, CLE magnetic charging cable connectors having the features of the high life and short circuit protection, strong magnetic and safe etc, we are also focusing on developing high-performance connectors, our magnetic connector series provides all common functions.
Female Part- – –Specification of 4 Pin square male and female magnetic cable connector
| Products | 4 Pin square male and female magnetic cable connector |
| Model No. | MMA-0249 |
| Voltage & Current | 12 V, 1 A |
| Plastic Core | HTN plastic (265°C) UL 94 V-0 |
| Pins | Copper,phosphor & beryllium copper, SUS |
| Gold-plating over Ni | |
| Environment | Anti-corrosion,48 hours salt-spray test |
| Installation | Screw fixation,solder,structure limit |
| Certification | RoHs, Reach, HF |
| Application | |
| Downloaded | Drawing |
Attention:
1.Magnet use NdFeB material, it’s can keep the magnetic force forever (except high temperature、broken、same pole connection)
2.Magnet exist magnetic field interference
Male Part- – –Specification of 4 Pin square male and female magnetic cable connector
| Products | 4 Pin square male and female magnetic cable connector |
| Model No. | CMA-0254 |
| Voltage & Current | 12 V, 1 A |
| Cable Shape | Round cable, flat cable |
| Material | PVC, TPE, Silica gel |
| Cable End | USB, JST,Adapter, Open circuit |
| Certification | RoHs, Reach, HF |
| Application | |
| Downloaded | Drawing |
Attention:
1.Magnet use NdFeB material, it’s can keep the magnetic force forever (except high temperature、broken、same pole connection)
2.Magnet exist magnetic field interference
3.Can design short-circuit protection
